Voltron®

Electrical insulation materials Americas

To meet the demanding requirements regarding corona resistance, Energy Solutions offers tailored Voltron® systems. They are suitable where high corona resistance of magnet wire dielectrics is required in specific industries and applications. Generally, our patented Voltron® systems are a combination of at least two Voltatex® products - a basecoat and a topcoat – and some contain a primer too. Voltron® systems are characterized by a high storage stability and they don’t need to be stirred up.

Product range

Voltron®

CR Systems Wire Enamel Ratio of WE Passes * Magnet Wire Range Mechanical Stability Chemical Stability Corona Resistance
Voltron® System 1210 Voltatex® 7740 base coat 100% >10 standard round: 0.3 - 2.00 mm + + +++
Voltron® System 1220

Voltatex® 7740 base coat

Voltatex® 8227 top coat

85.0% +/- 2.5%

15.0% +/- 2.5%

>10



>3



standard round: 0.3 - 2.00 mm

++ ++ ++
Voltron® System 1230

Voltatex® 7740 base coat

Voltatex® 8227 top coat

70.0% +/- 5.0%

30.0% +/- 5.0%

>8



>3



standard round: 0.3 - 2.00 mm

++ ++ +
Voltron® System 1321

Voltatex® 9127 primer

Voltatex® 7740 base coat

Voltatex® 8227 top coat

7.5% +/- 2.5%

77.5% +/- 5.0%

15.0% +/- 5.0%

>1-2



>7



>2



heavy round: >2.00 mm

+++ ++ +
Voltron® System 2230

Voltatex® 7740 base coat

Voltatex® 8534 top coat

70.0% +/- 5.0%

30.0% +/- 5.0%

>7



>3



standard round: 0.3 - 2.00 mm

++ +++ +++
Voltron® System 2240 Voltatex® 8534 base coat 100% >15 standard round: 0.3 - 2.00 mm +++ ++ +++
Voltron® System 2250

Voltatex® 9127 Primer

Voltatex® 8536 base coat

7.5% +/- 2.5%

92.5% +/- 2,5%

1-2



>13



rectangular / square

+++ ++ +++
Voltron® System 3230

Voltatex® 7340 AX base coat

Voltatex® 8536 top coat

70.0% +/- 5.0%

30.0% +/- 5.0%

>7



>3



standard round: 0.3 - 2.00 mm

++ + +++
